HT12E Encoder IC – 4-Bit RF Encoder for Wireless Remote Control and Infrared Transmission Systems

The HT12E Encoder IC – 4-Bit RF Encoder is a member of the 212 series of encoders designed for use in wireless and infrared remote control systems. It is typically paired with an HT12D decoder IC and enables reliable communication between a transmitter and receiver using RF or IR transmission mediums.

This IC encodes 12-bit parallel input data—comprising 8 address bits and 4 data bits—into a serial output, suitable for transmission through an RF module. It features a Transmission Enable (TE) pin which, when held low, initiates continuous data encoding and transmission. The HT12E is ideal for simple wireless control systems including home automation, toy control, security systems, and remote-controlled devices.

🔧 Key Features

• Encodes 12-bit parallel input (8 address + 4 data)
• Serial output suitable for RF/IR transmission
• Transmission enabled via active-low TE pin
• Compatible with HT12D decoder IC
• Built-in oscillator with external resistor control
• Low power CMOS design

📐 Technical Specifications

📌 Applications

• Wireless RF remote control systems
• Infrared remote transmitters
• Home automation and appliance control
• Security and alarm systems
• Toy and model control interfaces

💡 Why Choose This Product?

The HT12E Encoder IC provides a reliable and straightforward solution for converting parallel input to serial output for RF/IR transmission. It is essential in building wireless control systems and is widely used in embedded electronics due to its stability, low power consumption, and ease of integration.

📦 Package Includes

• 1 × HT12E Encoder IC – DIP-18
